Key Features
Technical Specifications
Key Specs
Top Speed28 mph
RangeUp to 50 miles
Power System
Motor750W BAFANG hub motor
Battery48V 15Ah LG removable
Battery Capacity720Wh (LG 21700 cells)
ChargerInput 100–240V~ 2.8A max; Output 54.6V⎓2.0A; aviation connector; UL listed
Motor Peak1275W peak; 80 Nm max torque
Controller48V 25A peak
Pedal AssistCadence sensor
ThrottleThumb throttle
Brake System
BrakesHydraulic disc brakes
Transmission
GearingShimano 7‑speed
Frame Details
Frame6061 aluminum step‑thru
Front SuspensionHydraulic suspension fork
Frame FeaturesRemovable battery; internal routing
Tire
TiresKenda 26×4.0
Lighting
Headlight48V 10W LED
Front Light48V 10W LED
Display
DisplayMultifunctional color‑screen LCD
General
ClassClass 3 (28 mph pedal assist)
Top Speed (Throttle)20 mph
Range DetailsAvg. 50 miles PAS; up to 50 on Level 1; ~30 on throttle
Wheels
Rim MaterialAluminum
Rim Size26 × 3.0
Front Spokes13K × 243
Rear Spokes12K × 198
Drivetrain
ShifterShimano, 7‑speed
Rear DerailleurShimano, long cage
Crank & Chainring52T, 170 mm alloy crank
Freewheel7‑speed
PedalsAlloy platform
Components
SaddleComfortable wide saddle
HandlebarAlloy, 750 mm width
GripsNylon lock‑on
Brake Rotor180 mm × 1.9 mm
KickstandSide kickstand
SeatpostØ31.6 × 350 mm (forged alloy)
StemBar bore Ø31.8 mm; clamp I.D. Ø28.6 mm; height 40 mm; rise 0°
Weight
Net Weight32 kg (70.5 lb)
Gross Weight42 kg (92.6 lb)
Battery Weight4.2 kg (9.3 lb)
Payload Capacity150 kg (330 lb)
Size
Product Size1975 × 1205 × 750 mm
Packing Size1630 × 350 × 830 mm
