Key Features
Technical Specifications
Key Specs
Top Speed46 mph
Range31 miles
Weight (excl. battery)57 kg (17/14); 54 kg (14/12)
Max Load75 kg
Power System
Rated Input Voltage72V
ControllerFOC sine‑wave vector, 72V 30A
Undervoltage Protection61V
Charger Output84.6V 6A (110–250VAC input)
Battery Capacity72V 1440Wh
Charge Time3–6 hours
Motor
Rated Power2000 W
Maximum Power4.5 kW
Rated Torque39 Nm
Max Motor Speed4200 r/min
Climbing Angle40°
CoolingNatural cooling
Brake System
Front Brake203 mm, 4‑piston hydraulic
Rear Brake203 mm, 2‑piston hydraulic
Tire
Front Wheel/Tire17×1.6 or 14×1.4 rim; 70/100‑17 or 60/100‑14 tire
Rear Wheel/Tire14×1.85 or 12×1.6 rim; 3.0‑14 or 70/100‑12 tire
Suspension
Front ForkDual shoulder, 110 mm travel
Rear ShockAdjustable hydraulic, 60 mm travel
Size
Dimensions (L×W×H)1640×671×990 mm (17/14); 1580×671×960 mm (14/12)
Wheelbase1081 mm / 1073 mm
Seat Height760 mm (17/14); 735 mm (14/12)
Ground Clearance270 mm (17/14); 240 mm (14/12)
Protection
Motor & Controller IPIP66
Battery & Connectors IPIP55
Display
InstrumentLCD
Connectivity
Comm PortCAN
